Specifications

Processing size range

Min. Width of work-piece

: 50 mm

Max. Width of work-piece

: 1200 mm

Max. Length of work-piece

: 3600 mm

Min. Length of work-piece

: 250 mm

Max. Thickness of work-piece

: 48 mm

Min. Thickness of work-piece

: 10 mm

Working Stoke & Max. Position speed

X axis

: 5000 mm – 130 m/min

Y axis

:  1680 mm -  80 m/min

Z axis

:  90 mm -  30 m/min

U axis

:  5000 mm - 130 m/min

V axis

:  1200 mm - 80 m/min

W axis

:  100mm – 30 m/min

A axis

: 1260mm – 30 m/min

Y2 axis

:  1500 mm -  80 m/min

Z2 axis

:  90 mm -  30 m/min

Drilling unit

Vertical spindles

: 28 ( X axis) + 9 ( Y axis)

Horizontal

: 16

Drilling box motor speed

: 3400 rpm

 Drilling motor power

: 2.2 kw*2

Milling unit

Milling motor power

: 3.5 kw x 2

Spindle speed

: 18000 rmp

Other data

Working table height

: 960 mm

Total power

: 25.6 kw

Voltage

: 380V/50Hz

Air pressure

: 0.7-0.8Mpa

Netweight

: 3900kg

Machine

: 5800x2840x2200mm
