3/4" AIR OPERATED DIAPHRAGM PUMP
Model : ADP-0145
| Features |
- Unlike cylindrical structures,which are easily jammed by impurities in supplied air , this swing type
air valve is suited for poor air supply conditions.
- Entre pump is easy to maintain.Parts maintenance or change are conveniently done without removing the unit.
- Safe are conveniently done without removing the unit.
- Safe and easy to operate
|
| Specifications |
| Pressure ratio : 1:1 |
Max. output pressure :7.2 kg/cm2 |
| Max. continuous flow :25 lpm |
Max. suction lift level : 5 m ( 12ft) |
| Max. air consumption :14 scfm |
Max. solids convey : 1.0m m(1/10in.) |
| Suitable viscosity : 1000 cps |
Temperature range :5 -65 ℃ |
| Paint outlet size : 3/4"pt(f) |
Noise level :80 db(A) |
| Paint inlet size :3/4"pt(f) |
Diaphragm material :UPE+ Teflon |
| Air inlet size :1/4"pt(f) |
Dimensions(mm) :208 x 175 x 274 mm |
| Workplace air pressure range :0.7~ 7.2 kg/cm2 |
Pump body(N.W) :4.2kgs |
| Pump material Aluminum |
Package weight(Standard) :9.2 kgs |
|
