WIDE BELT SANDERS (4’ CAPACITY)

  • :PR-52D/PR-52A/PR-52DA
  • :Taiwan
  • :12 months
  • :Call
  • :

WIDE BELT SANDERS (4’ CAPACITY)

MODEL: PR-52D/PR-52A/PR-52DA

may-cha-nham-thung-1-3m-PR52DA
Features
- PANEL CLEANING BRUSH ROLLER
Built at outfeed end of the machine, this panel cleaning brush roller clean powder on the sanded panel.
FEED CONTROLLED BY FREQUENCY INVERTER
Used for adjusting the sanding belt speed. (Use together with hollow shaft speed reducer)
VARIABLE SPEED UNIT
The conveyor belt speed is controlled by a variable speed unit. Feed speed can be varied as desired to suit all types of workpiece material,assuring superior sanding quality.
SANDING BELT QUICK CHANGE DEVICE
The sanding belt is changed quickly for time saving and convenience
CONVEYOR BELT TRACKING CONTROL
The conveyor belt tracking is pneumatically controlled to effectively prevent out-of-track
Specifications
may-cha-nham-thung-1-3m2
Working width
1270mm
1270mm
1270mm
Working height
125 mm
125 mm
150mm
Main motor standard
25 HP
25 HP
20, 20HP
Feed motor
3HP
3HP
3HP
Table hoist motor
1/2HP
1/2HP
1/2HP
Feed speeds (Variable)
6-23 M/min
6-23 M/min
6-23 M/min
Sanding belt size
1320x 1905 mm
1320x 1905 mm
1320x 1905 mm
Compressed air required
5 kg/cm²
5 kg/cm²
5 kg/cm²
Exhaust volume requirement
3500 M³/Hr
3500 M³/Hr
6860 M³/Hr
Net weight
1800 kg
1800 kg
2500kg
Gross weight
2050 kg
2050 kg
3000kg
Dimensions
1905x1778x1930 mm
1905x1778x1930 mm
1930x2083x1956 mm
Packing size
2057x1930x2108 mm
2057x1930x2108 mm
2032x1854x2159 mm
