SEGMENTED PIANO PAD SANDER 1300MM
- :BKM-52PWWF
- :Tai Wan
- :12 Months
- :Call
- :
 |  |
SEGMENTED PIANO PAD SANDER 1300MM
Model: BKM-52PWWF
|
Characteristics
|
|
|
- Adopt the electromagnetic type segmented pad to give the most accurate sanding performance.
- Each individual pressure element continuously adapts to the respective workpiece shape.
- Automatic adoption and compensation within a workpiece or among several workpieces.
- The pressure beam with more individual pressure elements: flexible, solid and maintenance-free.
- The automatic workpiece sensing and graphic touch-screen terminal with the integrated fault-finding-system. Optional programming memories for fast conversion to different wood and lacquer types ensure highest sanding quality.
|
|
|
Specifications
|
|
|
Max. Working width
|
1350 mm
|
|
Max. Working thickness
|
125 mm
|
|
1st segmented pad belt power
|
25 hp
|
|
2nd segmented pad wide belt power
|
25 hp
|
|
3rd polishing roller power
|
3 hp
|
|
4th dust removing brush roller power
|
3 hp
|
|
Feed motor
|
5 hp
|
|
Table hoist motor
|
1 hp
|
|
Vacuum power
|
5 hp
|
|
Touch screen size
|
14”
|
|
Feed speed range
|
3-12±5% (m/min)
|
|
1st sanding belt size
|
150 x 5000 mm
|
|
2nd sanding belt size
|
1380 x 2616 mm
|
|
Working pressure
|
6 kg/cm2
|
|
