CNC MULTI-SPINDLE SLOT MILLING MACHINE
YOM-5 CNC multi-spindle Slot milling machine is ideal for high speed slot milling on straight and curved wood. This machine is designed with 5 spindles, allowing for machining 5 pieces of wood simultaneously. Equipped with an advanced CNC controller, the machine makes slot milling operations more flexible and easy.
- :YOM-5
- :Taiwan
- :12 month
- :Call
- :
 |  |
CNC MULTI-SPINDLE SLOT MILLING MACHINE
Model: YOM-5
| Features | |
|
YOM-5 CNC multi-spindle Slot milling machine is ideal for high speed slot milling on straight and curved wood. This machine is designed with 5 spindles, allowing for machining 5 pieces of wood simultaneously. Equipped with an advanced CNC controller, the machine makes slot milling operations more flexible and easy. + Suitable for high speed slot milling for kitchen cabinet frames, chair legs and chair legs, etc.
+ Applicable for straight and curved wood.
+ 5 spindles are simultaneously controlled. Each spindle is individually controlled by a frequency inverter.
+ Powerful CNC controller permits slot milling to be performed with ease and helps to dramatically increase throughput.
+ X,Y,Z-axis movements are driven by servo motors with high speed and high positioning accuracy.
+ X-axis employs high precision ground rack for transmission. Y,Z-axis are transmitted through ball screws.
+ X,Y,Z-axis slideways and clamping mechanism slideways are fitted with linear motion guides.
  |
|
| Specifications | |
|
Maximum workpiece size
|
2800 x 85 x 100 mm
|
|
Number of spindle
|
05 pcs
|
|
Max. mortise width
|
85 mm
|
|
Max. mortise depth
|
40 mm
|
|
Drilling depth
|
100mm
|
|
Spindle speed
|
18000 RPM
|
|
Spindle motor
|
3HPx5
|
|
X-axis
|
1,5 kw x1
|
|
Y-axis
|
1 kw x1
|
|
Z-axis
|
1 kw x1
|
|
Dust hood outlet diameter
|
75 mm
|
|
Working air pressure
|
6 Bar
|
|
Machine dimensions
|
3710 x 1870 x 1980 mm
|
|
Net weight
|
3100 Kg
|
|
Gross weight
|
3150 Kg
|
