Automatic Paint Door Machine

Automatic Paint Door Machine
  • Suitable for all kinds of solid wood door, wood composite door, steel wooden door and different kinds of doors and windows.

  • :FXF250M
  • :Taiwan
  • :12 month
  • :Call
  • :

Automatic Paint Door Machine

Model: FXF250M

may-son-cua-tu-dong-FXF250M
Feature
The pneumatic rotary double-positioning feeding and automatic turnover mechanism enables the machine to paint the door’s six sides once time which saves working procedures, improve efficiency and ensure the painting effect
FXF250M_-2
Only two ordinary workers can finish the whole process. The capacity is 160-190 doors per day (8 hours).
FXF250M_-3
Touching type computer digital operation machine or automatic detection machine are provided. Both of them are easy to learn. Controlling the spray gun’s moving route through the computer to imitate manual painting, which ensures smooth painted surface and reaches the corners being painted.
FXF250M_-1

The machine is easy to operated and not rely on painting technique. It shortens the Production cycle, reduces paint cost and labor cost.
Specifications
Dimensions
4.5 x 4.4 x 2.5M
The weight of the machine
2200kg
Maximum machining lengt
2.5M
Maximum working width
1.2M
Min working width
0.15M
Gun movement speed
00~1800MM/S
Gun caliber
0.8/1.0/1.3
Servo motor ( Total )
4KW
Air pressure
0.6KPA
Types of paint
PE, PC, PU, UC, XU, UV, Water paint
Air consumptions
700-900L/Min
The amount of paint used
80-300g/m2
Using the power
380V   50Hz
